yaze Namespace Reference

Namespaces
namespace	anonymous_namespace{controller.cc}
namespace	anonymous_namespace{font_loader.cc}
namespace	anonymous_namespace{rom.cc}
namespace	app
namespace	cli
namespace	core
namespace	editor
	Editors are the view controllers for the application.
namespace	emu
	SNES Emulation and debugging tools.
namespace	gfx
	Contains classes for handling graphical data.
namespace	gui
	Graphical User Interface (GUI) components for the application.
namespace	i18n
namespace	ios
namespace	net
namespace	platform
namespace	project
namespace	rom
namespace	test
namespace	util
namespace	zelda3
	Zelda 3 specific classes and functions.

Classes
struct	AppConfig
	Configuration options for the application startup. More...
class	Application
	Main application singleton managing lifecycle and global state. More...
class	AssetLoader
	Cross-platform asset file loading utility. More...
class	Controller
	Main controller for the application. More...
struct	Event
class	EventBus
struct	FontConfig
struct	FontState
struct	GraphicsLoadDiagnostics
class	Json
class	Rom
	The Rom class is used to load, save, and modify Rom data. This is a generic SNES ROM container and does not contain game-specific logic. More...
class	ScopedRomTransaction
struct	SheetDiagnostics
class	TimingManager
	Provides accurate timing for animations and frame pacing. More...
class	Transaction

Enumerations
enum class	StartupVisibility { kAuto , kShow , kHide }
	Tri-state toggle used for startup UI visibility controls. More...
enum class	AssetLoadMode { kAuto , kFull , kLazy }
	Asset loading mode for editor resources. More...
enum class	CopierHeaderReason { kNone , kSizeAlignment , kInternalHeaderOffset }
	Why a copier header was recognized at the start of a ROM file. More...

Functions
absl::Status	LoadPackageFonts ()
void	SetActiveFontIndex (int index)
absl::Status	ReloadPackageFont (const FontConfig &config)
absl::Status	LoadFontFromMemory (const std::string &name, const std::string &data, float size_pixels)
void	LoadSystemFonts ()
StartupVisibility	StartupVisibilityFromString (absl::string_view value)
std::string	StartupVisibilityToString (StartupVisibility value)
AssetLoadMode	AssetLoadModeFromString (absl::string_view value)
std::string	AssetLoadModeToString (AssetLoadMode value)
CopierHeaderReason	DetectCopierHeader (const uint8_t *data, size_t size)
const char *	CopierHeaderReasonName (CopierHeaderReason reason)
uint32_t	SnesToPc (uint32_t addr) noexcept
uint32_t	PcToSnes (uint32_t addr)
uint32_t	Get24LocalFromPC (uint8_t *data, int addr, bool pc=true)
int	AddressFromBytes (uint8_t bank, uint8_t high, uint8_t low) noexcept
uint32_t	MapBankToWordAddress (uint8_t bank, uint16_t addr) noexcept

Variables
FontState	font_registry
constexpr size_t	kCopierHeaderSize = 0x200
	Size of the SMC/SWC copier header that some ROM dumps start with.

Enumeration Type Documentation

StartupVisibility

enum class yaze::StartupVisibility

strong

Tri-state toggle used for startup UI visibility controls.

kAuto - Use existing runtime logic (legacy behavior) kShow - Force the element to be shown on startup kHide - Force the element to be hidden on startup

Enumerator
kAuto
kShow
kHide

Definition at line 18 of file startup_flags.h.

AssetLoadMode

enum class yaze::AssetLoadMode

strong

Asset loading mode for editor resources.

kAuto - Choose based on runtime (e.g., headless/server => lazy). kFull - Load all editor assets on ROM load (legacy behavior). kLazy - Defer editor asset loading until first use.

Enumerator
kAuto
kFull
kLazy

Definition at line 31 of file startup_flags.h.

CopierHeaderReason

enum class yaze::CopierHeaderReason

strong

Why a copier header was recognized at the start of a ROM file.

Enumerator
kNone
kSizeAlignment
kInternalHeaderOffset

Definition at line 29 of file rom.h.

Function Documentation

LoadPackageFonts()

absl::Status yaze::LoadPackageFonts

(

)

Definition at line 135 of file font_loader.cc.

References font_registry, yaze::FontState::fonts, and RETURN_IF_ERROR.

Referenced by yaze::core::CreateWindow(), yaze::platform::IOSWindowBackend::InitializeImGui(), yaze::platform::NullWindowBackend::InitializeImGui(), and yaze::platform::SDL2WindowBackend::InitializeImGui().

SetActiveFontIndex()

void yaze::SetActiveFontIndex

(

int

index

)

Definition at line 157 of file font_loader.cc.

Referenced by yaze::editor::SettingsPanel::DrawAppearanceSettings(), and yaze::editor::EditorManager::InitializeServices().

ReloadPackageFont()

absl::Status yaze::ReloadPackageFont

(

const FontConfig &

config

)

Definition at line 168 of file font_loader.cc.

References yaze::FontConfig::font_path, yaze::FontConfig::font_size, and RETURN_IF_ERROR.

LoadFontFromMemory()

absl::Status yaze::LoadFontFromMemory	(	const std::string &	name,
		const std::string &	data,
		float	size_pixels )

Definition at line 181 of file font_loader.cc.

LoadSystemFonts()

void yaze::LoadSystemFonts

(

)

StartupVisibilityFromString()

StartupVisibility yaze::StartupVisibilityFromString ( absl::string_view value )

inline

Definition at line 37 of file startup_flags.h.

References kAuto, kHide, and kShow.

Referenced by BuildAppConfig().

StartupVisibilityToString()

std::string yaze::StartupVisibilityToString ( StartupVisibility value )

inline

Definition at line 49 of file startup_flags.h.

References kAuto, kHide, and kShow.

AssetLoadModeFromString()

AssetLoadMode yaze::AssetLoadModeFromString ( absl::string_view value )

inline

Definition at line 61 of file startup_flags.h.

References kAuto, kFull, and kLazy.

Referenced by BuildAppConfig().

AssetLoadModeToString()

std::string yaze::AssetLoadModeToString ( AssetLoadMode value )

inline

Definition at line 72 of file startup_flags.h.

References kAuto, kFull, and kLazy.

DetectCopierHeader()

CopierHeaderReason yaze::DetectCopierHeader	(	const uint8_t *	data,
		size_t	size )

Returns how a copier header was recognized in data, or kNone. A file whose SNES internal header is valid only without skipping 0x200 bytes is never treated as headered.

Definition at line 378 of file rom.cc.

References kCopierHeaderSize, kInternalHeaderOffset, kNone, and kSizeAlignment.

Referenced by yaze::anonymous_namespace{rom.cc}::MaybeStripCopierHeader().

CopierHeaderReasonName()

const char * yaze::CopierHeaderReasonName

(

CopierHeaderReason

reason

)

Definition at line 402 of file rom.cc.

References kInternalHeaderOffset, kNone, and kSizeAlignment.

Referenced by yaze::cli::handlers::RomInfoCommandHandler::Execute(), yaze::cli::RomDoctorCommandHandler::Execute(), and yaze::anonymous_namespace{rom.cc}::MaybeStripCopierHeader().

SnesToPc()

uint32_t yaze::SnesToPc ( uint32_t addr )

inlinenoexcept

Definition at line 8 of file snes.h.

Referenced by yaze::editor::BuildDictionaryEntries(), yaze::zelda3::BuildGfxSheetInventory(), yaze::core::BuildGfxSheetWritePolicy(), yaze::zelda3::TitleScreen::BuildTileset(), yaze::editor::anonymous_namespace{dungeon_editor_v2_persistence.cc}::CollectDirtyPotItemWriteRanges(), yaze::zelda3::CollectRoomGfx(), yaze::cli::handlers::anonymous_namespace{dungeon_commands.cc}::CollectRoomHeaderWriteRanges(), yaze::zelda3::anonymous_namespace{dungeon_stream_allocator.cc}::DecodePointer(), yaze::zelda3::Overworld::DecompressAllMapTilesParallel(), yaze::zelda3::ObjectDrawer::DrawChestHoleOverlay(), yaze::editor::AssemblyEditor::DrawDisassemblyContent(), yaze::zelda3::anonymous_namespace{dungeon_stream_allocator.cc}::EncodePointer(), yaze::cli::handlers::DungeonRoomHeaderCommandHandler::Execute(), yaze::editor::MessageEditor::ExpandedInspectionRange(), yaze::zelda3::anonymous_namespace{dungeon_stream_allocator.cc}::FindFirstFit(), Get24LocalFromPC(), yaze::zelda3::GetChestTableWriteRanges(), yaze::zelda3::GetGraphicsAddress(), yaze::zelda3::RoomLayout::GetLayoutAddress(), yaze::zelda3::anonymous_namespace{room.cc}::GetObjectPointerTablePc(), yaze::zelda3::anonymous_namespace{room.cc}::GetSpritePointerTablePc(), yaze::editor::anonymous_namespace{message_source_sync.cc}::IsCanonicalMappedLoRomAddress(), yaze::cli::handlers::anonymous_namespace{message_commands.cc}::IsCanonicalMappedLoRomAddress(), yaze::cli::handlers::anonymous_namespace{dungeon_edit_commands.cc}::IsLoRomDataPointer(), yaze::zelda3::Room::LoadAnimatedGraphics(), yaze::zelda3::Room::LoadBlocks(), yaze::zelda3::Room::LoadChests(), yaze::zelda3::LoadCustomCollisionMap(), yaze::zelda3::LoadDungeonMaps(), yaze::zelda3::PitDamageTable::LoadFromRom(), yaze::zelda3::LoadGfxGroups(), yaze::zelda3::Inventory::LoadItemIcons(), yaze::zelda3::LoadItems(), yaze::zelda3::RoomLayout::LoadLayout(), yaze::zelda3::LoadLegacyWaterGateZones(), yaze::editor::LoadMessageSource(), yaze::zelda3::Room::LoadObjects(), yaze::zelda3::Room::LoadPotItems(), yaze::zelda3::LoadRoomHeaderFromRom(), yaze::zelda3::TitleScreen::LoadTitleScreen(), yaze::core::anonymous_namespace{hack_manifest.cc}::ParseAddressRanges(), yaze::core::anonymous_namespace{hack_manifest.cc}::ParseDungeonStreamLayout(), yaze::core::anonymous_namespace{hack_manifest.cc}::ParseDungeonStreamLayouts(), yaze::core::anonymous_namespace{hack_manifest.cc}::ParseGraphicsSheetLayout(), yaze::core::anonymous_namespace{hack_manifest.cc}::ParseLoRomAddress(), yaze::core::anonymous_namespace{hack_manifest.cc}::ParseProtectedRegions(), yaze::core::anonymous_namespace{hack_manifest.cc}::PcRangeContains(), yaze::zelda3::PlanDungeonStreamRepack(), yaze::zelda3::anonymous_namespace{room.cc}::PreflightBlocksLoaderDestinations(), yaze::cli::handlers::anonymous_namespace{message_commands.cc}::PreflightExpandedMutation(), yaze::editor::ReadDictionaryEntryBytes(), yaze::zelda3::ReadGfxSheetPc(), yaze::zelda3::ReadObjectDrawCode(), yaze::zelda3::anonymous_namespace{room.cc}::ReadRoomObjectAddressPc(), yaze::zelda3::anonymous_namespace{room.cc}::ReadRoomPotItemAddressPc(), yaze::zelda3::anonymous_namespace{room.cc}::ReadRoomSpriteAddressPc(), yaze::cli::handlers::anonymous_namespace{dungeon_edit_commands.cc}::ResolveDoorTypeTarget(), yaze::zelda3::anonymous_namespace{game_data.cc}::ResolveGfxGroupTables(), yaze::zelda3::ResolveMenuPaletteFromSymbol(), yaze::cli::handlers::anonymous_namespace{dungeon_edit_commands.cc}::ResolveRoomHeaderPcStrict(), yaze::cli::handlers::anonymous_namespace{dungeon_edit_commands.cc}::ResolveRuntimePotItemStream(), yaze::zelda3::TitleScreen::Save(), yaze::zelda3::SaveAllPits(), yaze::zelda3::SaveItems(), yaze::zelda3::Overworld::SaveMap16Expanded(), yaze::zelda3::Overworld::SaveMap32Expanded(), yaze::editor::DungeonEditorV2::SaveRoomData(), yaze::zelda3::Room::SaveRoomHeader(), yaze::zelda3::PitDamageTable::SaveToRom(), yaze::editor::PolyhedralEditorPanel::TablePc(), yaze::core::ToDungeonStreamAllocatorLayout(), yaze::editor::anonymous_namespace{polyhedral_editor_panel.cc}::ToPc(), yaze::gui::DungeonObjectEmulatorPreview::TriggerEmulatedRender(), yaze::gui::DungeonObjectEmulatorPreview::TriggerStaticRender(), yaze::editor::MemoryEditor::Update(), yaze::editor::anonymous_namespace{dungeon_editor_v2_connection_edits.cc}::ValidateConnectionRoomSource(), yaze::zelda3::anonymous_namespace{water_fill_zone.cc}::ValidateCustomCollisionDoesNotOverlapWaterFillReserved(), yaze::cli::anonymous_namespace{graphics_doctor_commands.cc}::ValidateGroupTables(), yaze::zelda3::anonymous_namespace{dungeon_stream_allocator.cc}::ValidateKnownPointerTableSource(), yaze::editor::anonymous_namespace{message_source_sync.cc}::ValidateLayoutAndGetCapacity(), yaze::cli::anonymous_namespace{overworld_doctor_commands.cc}::ValidateMapPointers(), yaze::cli::handlers::anonymous_namespace{dungeon_edit_commands.cc}::ValidateObjectSaveManifestConflicts(), yaze::cli::handlers::anonymous_namespace{dungeon_commands.cc}::ValidateObjectStreamHeaderManifestConflicts(), yaze::editor::anonymous_namespace{dungeon_editor_v2_room_transfer.cc}::ValidateTransferHeaderOwnership(), and yaze::zelda3::WriteTrackCollision().

PcToSnes()

uint32_t yaze::PcToSnes ( uint32_t addr )

inline

Definition at line 17 of file snes.h.

Referenced by yaze::cli::handlers::anonymous_namespace{dungeon_edit_commands.cc}::AddDungeonPaletteScope(), yaze::core::HackManifest::AnalyzePcWriteRanges(), yaze::zelda3::BuildDungeonMapWritePlan(), yaze::zelda3::anonymous_namespace{dungeon_stream_allocator.cc}::EncodePointer(), yaze::cli::handlers::DungeonGetPaletteCommandHandler::Execute(), yaze::cli::handlers::DungeonSetPaletteColorCommandHandler::Execute(), yaze::cli::handlers::DungeonSetDoorTypeCommandHandler::Execute(), yaze::cli::handlers::DungeonListPotItemsCommandHandler::Execute(), yaze::cli::handlers::DungeonSetPotItemCommandHandler::Execute(), Get24LocalFromPC(), yaze::editor::anonymous_namespace{message_source_sync.cc}::IsCanonicalMappedLoRomAddress(), yaze::cli::handlers::anonymous_namespace{message_commands.cc}::IsCanonicalMappedLoRomAddress(), yaze::cli::handlers::anonymous_namespace{dungeon_edit_commands.cc}::IsLoRomDataPointer(), yaze::core::anonymous_namespace{hack_manifest.cc}::ParseLoRomAddress(), yaze::zelda3::Room::PlanObjectSave(), yaze::zelda3::RelocateSpriteData(), yaze::zelda3::SaveItems(), yaze::zelda3::Overworld::SaveMap16Expanded(), yaze::zelda3::Overworld::SaveMap32Expanded(), yaze::zelda3::Overworld::SaveMapOverlays(), yaze::zelda3::Overworld::SaveOverworldMaps(), yaze::zelda3::anonymous_namespace{dungeon_stream_allocator.cc}::ValidateAndNormalizeLayout(), and yaze::zelda3::WriteTrackCollision().

Get24LocalFromPC()

uint32_t yaze::Get24LocalFromPC ( uint8_t * data, int addr, bool pc = true )

inline

Definition at line 30 of file snes.h.

References PcToSnes(), and SnesToPc().

Referenced by yaze::editor::ReadAllTextData().

Here is the call graph for this function:

AddressFromBytes()

int yaze::AddressFromBytes ( uint8_t bank, uint8_t high, uint8_t low )

inlinenoexcept

Definition at line 39 of file snes.h.

Referenced by yaze::zelda3::GetGraphicsAddress().

MapBankToWordAddress()

uint32_t yaze::MapBankToWordAddress ( uint8_t bank, uint16_t addr )

inlinenoexcept

Definition at line 43 of file snes.h.

Variable Documentation

font_registry

FontState yaze::font_registry

inline

Definition at line 23 of file font_loader.h.

Referenced by yaze::gui::DrawFontManager(), and LoadPackageFonts().

kCopierHeaderSize

constexpr size_t yaze::kCopierHeaderSize = 0x200

inlineconstexpr

Size of the SMC/SWC copier header that some ROM dumps start with.

Definition at line 26 of file rom.h.

Referenced by DetectCopierHeader(), yaze::cli::handlers::anonymous_namespace{message_commands.cc}::LoadProjectMutationContext(), and yaze::anonymous_namespace{rom.cc}::MaybeStripCopierHeader().
