yaze::editor::MesenScreenshotEditorPanel Class Reference

WindowContent for Mesen2 live screenshot preview. More...

#include <agent_editor_panels.h>

Inheritance diagram for yaze::editor::MesenScreenshotEditorPanel:

Collaboration diagram for yaze::editor::MesenScreenshotEditorPanel:

Public Types
using	DrawCallback = std::function<void()>

Public Member Functions
	MesenScreenshotEditorPanel (DrawCallback draw_callback)
std::string	GetId () const override
	Unique identifier for this panel.
std::string	GetDisplayName () const override
	Human-readable name shown in menus and title bars.
std::string	GetIcon () const override
	Material Design icon for this panel.
std::string	GetEditorCategory () const override
	Editor category this panel belongs to.
std::string	GetWorkflowGroup () const override
	Optional workflow group for hack-centric actions.
std::string	GetWorkflowDescription () const override
	Optional workflow description for menus/command palette.
int	GetPriority () const override
	Get display priority for menu ordering.
void	Draw (bool *p_open) override
	Draw the panel content.
Public Member Functions inherited from yaze::editor::WindowContent
virtual	~WindowContent ()=default
virtual void	OnFirstDraw ()
	Called once before the first Draw() in a session.
virtual bool	RequiresLazyInit () const
	Whether this panel uses lazy initialization.
void	InvalidateLazyInit ()
	Reset lazy init state so OnFirstDraw() runs again.
virtual void	OnOpen ()
	Called when panel becomes visible.
virtual void	OnClose ()
	Called when panel is hidden.
virtual void	OnFocus ()
	Called when panel receives focus.
virtual WindowLifecycle	GetWindowLifecycle () const
	Get the lifecycle category for this window.
virtual WindowContextScope	GetContextScope () const
	Optional context binding for this window (room/selection/etc)
virtual WindowScope	GetScope () const
	Get the registration scope for this window.
virtual bool	IsEnabled () const
	Check if this panel is currently enabled.
virtual std::string	GetDisabledTooltip () const
	Get tooltip text when panel is disabled.
virtual std::string	GetShortcutHint () const
	Get keyboard shortcut hint for display.
virtual std::string	GetWorkflowLabel () const
	Optional workflow label for menus/command palette.
virtual int	GetWorkflowPriority () const
	Optional workflow ordering priority (lower sorts first).
virtual float	GetPreferredWidth () const
	Get preferred width for this panel (optional)
virtual bool	PreferAutoHideTabBar () const
	Whether the dock node hosting this panel should auto-hide its tab bar.
virtual bool	IsVisibleByDefault () const
	Whether this panel should be visible by default.
virtual std::string	GetParentPanelId () const
	Get parent panel ID for cascade behavior.
virtual bool	CascadeCloseChildren () const
	Whether closing this panel should close child panels.
void	DrawWithLazyInit (bool *p_open)
	Execute lazy initialization if needed, then call Draw()

Private Attributes
DrawCallback	draw_callback_

Additional Inherited Members
Protected Member Functions inherited from yaze::editor::WindowContent
void	InvalidateCache ()
	Invalidate all cached computations.
template<typename T >
T &	GetCached (const std::string &key, std::function< T()> compute)
	Get or compute a cached value.
bool	IsCacheValid () const
	Check if cache has been invalidated.
void	ClearCache ()
	Clear all cached values (more aggressive than InvalidateCache)

Detailed Description

WindowContent for Mesen2 live screenshot preview.

Polls screenshots from a running Mesen2 emulator and renders them as a GPU texture in the ImGui viewport.

Definition at line 426 of file agent_editor_panels.h.

Member Typedef Documentation

DrawCallback

using yaze::editor::MesenScreenshotEditorPanel::DrawCallback = std::function<void()>

Definition at line 428 of file agent_editor_panels.h.

Constructor & Destructor Documentation

MesenScreenshotEditorPanel()

yaze::editor::MesenScreenshotEditorPanel::MesenScreenshotEditorPanel ( DrawCallback draw_callback )

inlineexplicit

Definition at line 430 of file agent_editor_panels.h.

Member Function Documentation

GetId()

std::string yaze::editor::MesenScreenshotEditorPanel::GetId ( ) const

inlineoverridevirtual

Unique identifier for this panel.

Returns

Panel ID in format "{category}.{name}" (e.g., "dungeon.room_selector")

IDs should be:

• Lowercase with underscores
• Prefixed with editor category
• Unique across all panels

Implements yaze::editor::WindowContent.

Definition at line 433 of file agent_editor_panels.h.

GetDisplayName()

std::string yaze::editor::MesenScreenshotEditorPanel::GetDisplayName ( ) const

inlineoverridevirtual

Human-readable name shown in menus and title bars.

Returns

Display name (e.g., "Room Selector")

Implements yaze::editor::WindowContent.

Definition at line 434 of file agent_editor_panels.h.

GetIcon()

std::string yaze::editor::MesenScreenshotEditorPanel::GetIcon ( ) const

inlineoverridevirtual

Material Design icon for this panel.

Returns

Icon constant (e.g., ICON_MD_LIST)

Implements yaze::editor::WindowContent.

Definition at line 437 of file agent_editor_panels.h.

References ICON_MD_CAMERA_ALT.

GetEditorCategory()

std::string yaze::editor::MesenScreenshotEditorPanel::GetEditorCategory ( ) const

inlineoverridevirtual

Editor category this panel belongs to.

Returns

Category name matching EditorType (e.g., "Dungeon", "Overworld")

Implements yaze::editor::WindowContent.

Definition at line 438 of file agent_editor_panels.h.

GetWorkflowGroup()

std::string yaze::editor::MesenScreenshotEditorPanel::GetWorkflowGroup ( ) const

inlineoverridevirtual

Optional workflow group for hack-centric actions.

Returns

Non-empty group name to surface this panel in hack workflows.

Reimplemented from yaze::editor::WindowContent.

Definition at line 439 of file agent_editor_panels.h.

GetWorkflowDescription()

std::string yaze::editor::MesenScreenshotEditorPanel::GetWorkflowDescription ( ) const

inlineoverridevirtual

Optional workflow description for menus/command palette.

Reimplemented from yaze::editor::WindowContent.

Definition at line 440 of file agent_editor_panels.h.

GetPriority()

int yaze::editor::MesenScreenshotEditorPanel::GetPriority ( ) const

inlineoverridevirtual

Get display priority for menu ordering.

Returns

Priority value (lower = higher in list, default 50)

Reimplemented from yaze::editor::WindowContent.

Definition at line 443 of file agent_editor_panels.h.

Draw()

void yaze::editor::MesenScreenshotEditorPanel::Draw ( bool * p_open )

inlineoverridevirtual

Draw the panel content.

Parameters

p_open

Pointer to visibility flag (nullptr if not closable)

Called by WorkspaceWindowManager when the panel is visible. Do NOT call ImGui::Begin/End - the PanelWindow wrapper handles that. Just draw your content directly.

Implements yaze::editor::WindowContent.

Definition at line 445 of file agent_editor_panels.h.

References draw_callback_.

Member Data Documentation

draw_callback_

DrawCallback yaze::editor::MesenScreenshotEditorPanel::draw_callback_

private

Definition at line 452 of file agent_editor_panels.h.

Referenced by Draw().

---

The documentation for this class was generated from the following file:

• src/app/editor/agent/ui/window/agent_editor_panels.h
