yaze::zelda3::atlas Namespace Reference

Namespaces

namespace  anonymous_namespace{atlas_annotations.cc}

namespace  anonymous_namespace{atlas_json.cc}

namespace  anonymous_namespace{dungeon_atlas.cc}

namespace  anonymous_namespace{dungeon_door_edges.cc}


Classes

struct  AreaAnnotation

struct  AtlasAnnotations

struct  AtlasArea

struct  AtlasBadges

struct  AtlasColor

struct  AtlasDoor

struct  AtlasDoorFact

struct  AtlasItemIds

struct  AtlasKeyTableRow

struct  AtlasLink

struct  AtlasPlan

struct  AtlasRomIdentity

struct  AtlasSymbolRead

struct  DoorEdge

struct  DungeonAnnotation

struct  DungeonAtlas

struct  DungeonAtlasCollectOptions

struct  DungeonAtlasCounts

struct  DungeonAtlasInput

struct  DungeonAtlasJsonContext

struct  DungeonAtlasRoom

struct  DungeonAtlasRoomExtras

struct  LinkAnnotation

struct  Origin

struct  OverworldAnnotations

struct  OverworldEdgeAnnotation

struct  OverworldGateAnnotation

struct  OverworldMapAnnotation

struct  OverworldRegionAnnotation

struct  OverworldSectionAnnotation

struct  PlanAnnotation

struct  RoomAnnotation

struct  SymbolLinkAnnotation

struct  VanillaDungeonDefault


Enumerations

enum class  Provenance : uint8_t {
  kRom , kRegistry , kAnnotation , kSymbol ,
  kDefault
}

enum class  AtlasView : uint8_t { kDungeon , kOverworld }

enum class  AnnotationFormat : uint8_t { kAtlasV1 , kOracleRoomV0 , kOracleOverworldV0 }

enum class  RoomStatus : uint8_t {
  kInUse , kFree , kReclaimable , kOrphan ,
  kReserved
}

enum class  LinkKind : uint8_t {
  kEntrance , kHole , kSpawn , kStair ,
  kPit , kWarpTiles , kWarpTag , kPitDamage ,
  kTagPit , kAnnotation , kSymbol
}

enum class  DoorCategory : uint8_t {
  kOpen , kOneSided , kShutter , kKey ,
  kBigKey , kBomb , kExit , kKeyStairs ,
  kOther , kIgnore
}


Functions

const char * AnnotationFormatName (AnnotationFormat format)

std::optional< int > ParseAtlasId (const std::string &text)

absl::Status MergeAtlasAnnotationText (const std::string &text, const std::string &file_label, AtlasAnnotations *out, AnnotationFormat *format)

absl::Status MergeAtlasAnnotationFile (const std::string &path, AtlasAnnotations *out, AnnotationFormat *format)

void ApplyVanillaAtlasDefaults (AtlasAnnotations *out)

absl::StatusOr< AtlasAnnotations > LoadAtlasAnnotations (const std::vector< std::string > &files, const std::string &defaults)

const std::vector< AtlasColor > & AtlasAreaPalette ()

const std::vector< VanillaDungeonDefault > & VanillaDungeonDefaults ()

std::string DungeonAtlasToJson (const DungeonAtlas &atlas, const DungeonAtlasJsonContext &context, int indent)

const char * RoomStatusName (RoomStatus status)

const char * LinkKindName (LinkKind kind)

absl::StatusOr< std::map< std::string, uint32_t > > ReadWlaSymbols (const std::string &path)

absl::StatusOr< DungeonAtlasInput > CollectDungeonAtlasInput (Rom *rom, const DungeonAtlasCollectOptions &options)

DungeonAtlas BuildDungeonAtlas (const DungeonAtlasInput &input, const AtlasAnnotations &annotations)

const char * DoorCategoryName (DoorCategory category)

DoorCategory DoorCategoryForType (int door_type)

std::vector< AtlasDoor > OuterWallDoors (const std::vector< AtlasDoorFact > &doors)

std::vector< DoorEdge > PairDoorEdges (const std::vector< std::vector< AtlasDoor > > &doors_by_room)


Variables

constexpr int kAtlasRoomCount = 0x128

constexpr int kAtlasMapCount = 0xA0

constexpr AtlasColor kAtlasOtherColor {120, 120, 132}

constexpr AtlasColor kAtlasNoOwnerColor {30, 33, 40}

constexpr AtlasColor kAtlasInteriorColor {86, 90, 102}

constexpr char kDungeonAtlasJsonSchema [] = "yaze.atlas.dungeon/1"


Enumeration Type Documentation

◆ Provenance

enum class yaze::zelda3::atlas::Provenance : uint8_t
strong
Enumerator
kRom
kRegistry
kAnnotation
kSymbol
kDefault

Definition at line 50 of file atlas_annotations.h.

◆ AtlasView

enum class yaze::zelda3::atlas::AtlasView : uint8_t
strong
Enumerator
kDungeon
kOverworld

Definition at line 103 of file atlas_annotations.h.

◆ AnnotationFormat

enum class yaze::zelda3::atlas::AnnotationFormat : uint8_t
strong
Enumerator
kAtlasV1
kOracleRoomV0
kOracleOverworldV0

Definition at line 222 of file atlas_annotations.h.

◆ RoomStatus

enum class yaze::zelda3::atlas::RoomStatus : uint8_t
strong
Enumerator
kInUse
kFree
kReclaimable
kOrphan
kReserved

Definition at line 38 of file dungeon_atlas.h.

◆ LinkKind

enum class yaze::zelda3::atlas::LinkKind : uint8_t
strong
Enumerator
kEntrance
kHole
kSpawn
kStair
kPit
kWarpTiles
kWarpTag
kPitDamage
kTagPit
kAnnotation
kSymbol

Definition at line 48 of file dungeon_atlas.h.

◆ DoorCategory

enum class yaze::zelda3::atlas::DoorCategory : uint8_t
strong
Enumerator
kOpen
kOneSided
kShutter
kKey
kBigKey
kBomb
kExit
kKeyStairs
kOther
kIgnore

Definition at line 16 of file dungeon_door_edges.h.

Function Documentation

◆ AnnotationFormatName()

const char * yaze::zelda3::atlas::AnnotationFormatName ( AnnotationFormat format)

Definition at line 1316 of file atlas_annotations.cc.

References kAtlasV1, kOracleOverworldV0, and kOracleRoomV0.

◆ ParseAtlasId()

std::optional< int > yaze::zelda3::atlas::ParseAtlasId ( const std::string & text)

Definition at line 1328 of file atlas_annotations.cc.

Referenced by yaze::zelda3::atlas::anonymous_namespace{atlas_annotations.cc}::DocReader::Id().

◆ MergeAtlasAnnotationText()

absl::Status yaze::zelda3::atlas::MergeAtlasAnnotationText ( const std::string & text,
const std::string & file_label,
AtlasAnnotations * out,
AnnotationFormat * format )

Definition at line 1341 of file atlas_annotations.cc.

References yaze::zelda3::atlas::AtlasAnnotations::files, kAtlasV1, kOracleOverworldV0, kOracleRoomV0, and yaze::Json::parse().

Referenced by MergeAtlasAnnotationFile().

Here is the call graph for this function:

◆ MergeAtlasAnnotationFile()

absl::Status yaze::zelda3::atlas::MergeAtlasAnnotationFile ( const std::string & path,
AtlasAnnotations * out,
AnnotationFormat * format )

Definition at line 1383 of file atlas_annotations.cc.

References MergeAtlasAnnotationText().

Referenced by LoadAtlasAnnotations().

Here is the call graph for this function:

◆ ApplyVanillaAtlasDefaults()

void yaze::zelda3::atlas::ApplyVanillaAtlasDefaults ( AtlasAnnotations * out)

Definition at line 1398 of file atlas_annotations.cc.

References yaze::zelda3::atlas::DungeonAnnotation::code, yaze::zelda3::atlas::DungeonAnnotation::color, yaze::zelda3::atlas::DungeonAnnotation::color_origin, yaze::zelda3::atlas::Origin::Default(), yaze::zelda3::atlas::DungeonAnnotation::dungeon_id, yaze::zelda3::atlas::DungeonAnnotation::name, yaze::zelda3::atlas::DungeonAnnotation::origin, yaze::zelda3::atlas::AtlasAnnotations::vanilla_defaults, and VanillaDungeonDefaults().

Referenced by LoadAtlasAnnotations().

Here is the call graph for this function:

◆ LoadAtlasAnnotations()

absl::StatusOr< AtlasAnnotations > yaze::zelda3::atlas::LoadAtlasAnnotations ( const std::vector< std::string > & files,
const std::string & defaults )

Definition at line 1412 of file atlas_annotations.cc.

References ApplyVanillaAtlasDefaults(), and MergeAtlasAnnotationFile().

Referenced by yaze::cli::handlers::AtlasRenderCommandHandler::ExecuteWithContext().

Here is the call graph for this function:

◆ AtlasAreaPalette()

const std::vector< AtlasColor > & yaze::zelda3::atlas::AtlasAreaPalette ( )

Definition at line 5 of file atlas_defaults.cc.

Referenced by BuildDungeonAtlas(), and VanillaDungeonDefaults().

◆ VanillaDungeonDefaults()

const std::vector< VanillaDungeonDefault > & yaze::zelda3::atlas::VanillaDungeonDefaults ( )

Definition at line 16 of file atlas_defaults.cc.

References AtlasAreaPalette(), and kAtlasInteriorColor.

Referenced by ApplyVanillaAtlasDefaults().

Here is the call graph for this function:

◆ DungeonAtlasToJson()

std::string yaze::zelda3::atlas::DungeonAtlasToJson ( const DungeonAtlas & atlas,
const DungeonAtlasJsonContext & context,
int indent )

Definition at line 72 of file atlas_json.cc.

References yaze::zelda3::atlas::DungeonAtlas::annotation_files, yaze::zelda3::atlas::DungeonAtlas::areas, yaze::Json::array(), yaze::zelda3::atlas::DungeonAtlas::counts, DoorCategoryName(), yaze::Json::dump(), yaze::zelda3::atlas::DungeonAtlas::edges, yaze::Json::empty(), yaze::zelda3::atlas::DungeonAtlas::expanded_entrance_tables, yaze::zelda3::atlas::DungeonAtlasCounts::free, yaze::zelda3::atlas::DungeonAtlasJsonContext::generator, yaze::zelda3::atlas::DungeonAtlasCounts::in_use, yaze::zelda3::atlas::DungeonAtlasCounts::interior, kDungeonAtlasJsonSchema, yaze::zelda3::atlas::DungeonAtlas::key_table, yaze::zelda3::atlas::DungeonAtlas::legend_notes, yaze::zelda3::atlas::AtlasRomIdentity::name, yaze::zelda3::atlas::DungeonAtlasCounts::orphan, yaze::zelda3::atlas::DungeonAtlas::owners_from_project, yaze::zelda3::atlas::DungeonAtlas::plans, yaze::zelda3::atlas::DungeonAtlasJsonContext::project, yaze::zelda3::atlas::DungeonAtlasCounts::reclaimable, yaze::zelda3::atlas::DungeonAtlasCounts::reserved, yaze::zelda3::atlas::DungeonAtlas::rom, yaze::zelda3::atlas::DungeonAtlas::rooms, RoomStatusName(), yaze::zelda3::atlas::AtlasRomIdentity::sha1, yaze::zelda3::atlas::AtlasRomIdentity::size, yaze::zelda3::atlas::DungeonAtlas::symbols, yaze::zelda3::atlas::DungeonAtlas::title, and yaze::zelda3::atlas::DungeonAtlas::warnings.

Referenced by yaze::cli::handlers::AtlasRenderCommandHandler::ExecuteWithContext().

◆ RoomStatusName()

const char * yaze::zelda3::atlas::RoomStatusName ( RoomStatus status)

Definition at line 81 of file dungeon_atlas.cc.

References kFree, kInUse, kOrphan, kReclaimable, and kReserved.

Referenced by DungeonAtlasToJson().

◆ LinkKindName()

const char * yaze::zelda3::atlas::LinkKindName ( LinkKind kind)

Definition at line 97 of file dungeon_atlas.cc.

References kAnnotation, kEntrance, kHole, kPit, kPitDamage, kSpawn, kStair, kSymbol, kTagPit, kWarpTag, and kWarpTiles.

Referenced by yaze::zelda3::atlas::anonymous_namespace{atlas_json.cc}::LinkJson().

◆ ReadWlaSymbols()

absl::StatusOr< std::map< std::string, uint32_t > > yaze::zelda3::atlas::ReadWlaSymbols ( const std::string & path)

Definition at line 125 of file dungeon_atlas.cc.

References yaze::zelda3::name.

Referenced by CollectDungeonAtlasInput().

◆ CollectDungeonAtlasInput()

absl::StatusOr< DungeonAtlasInput > yaze::zelda3::atlas::CollectDungeonAtlasInput ( Rom * rom,
const DungeonAtlasCollectOptions & options )

Definition at line 161 of file dungeon_atlas.cc.

References yaze::zelda3::atlas::DungeonAtlasInput::census, yaze::zelda3::CollectRoomCensusInput(), yaze::util::ComputeSha1Hex(), yaze::Rom::data(), yaze::zelda3::atlas::AtlasDoorFact::direction, yaze::core::ProjectRegistry::dungeons, yaze::zelda3::atlas::DungeonAtlasInput::extras, yaze::Rom::filename(), yaze::Rom::is_loaded(), yaze::zelda3::atlas::DungeonAtlasCollectOptions::manifest, yaze::zelda3::RoomCensusOptions::manifest, yaze::zelda3::atlas::AtlasRomIdentity::name, yaze::zelda3::RoomCensusOptions::project, ReadWlaSymbols(), yaze::zelda3::atlas::DungeonAtlasCollectOptions::registry, yaze::zelda3::atlas::DungeonAtlasInput::registry_room_names, yaze::zelda3::atlas::DungeonAtlasInput::rom, yaze::zelda3::RoomCensusOptions::room_visitor, yaze::zelda3::atlas::AtlasRomIdentity::sha1, yaze::Rom::size(), yaze::zelda3::atlas::AtlasRomIdentity::size, yaze::zelda3::atlas::DungeonAtlasCollectOptions::symbol_links, yaze::zelda3::atlas::DungeonAtlasInput::symbol_reads, yaze::zelda3::atlas::DungeonAtlasInput::symbols_path, yaze::zelda3::atlas::DungeonAtlasCollectOptions::symbols_path, yaze::zelda3::atlas::AtlasDoorFact::tile_x, yaze::zelda3::atlas::AtlasDoorFact::tile_y, yaze::zelda3::atlas::AtlasDoorFact::type, yaze::zelda3::atlas::AtlasDoorFact::type_name, yaze::zelda3::atlas::DungeonAtlasCollectOptions::vanilla_rom, yaze::zelda3::RoomCensusOptions::vanilla_rom, and yaze::Rom::vector().

Referenced by yaze::cli::handlers::AtlasRenderCommandHandler::ExecuteWithContext().

◆ BuildDungeonAtlas()

DungeonAtlas yaze::zelda3::atlas::BuildDungeonAtlas ( const DungeonAtlasInput & input,
const AtlasAnnotations & annotations )

Definition at line 250 of file dungeon_atlas.cc.

References yaze::zelda3::atlas::DungeonAtlas::annotation_files, yaze::zelda3::atlas::DungeonAtlasRoom::area, yaze::zelda3::atlas::DungeonAtlasRoom::area_origin, yaze::zelda3::atlas::AtlasAnnotations::areas, yaze::zelda3::atlas::DungeonAtlas::areas, AtlasAreaPalette(), yaze::zelda3::atlas::DungeonAtlasRoom::badges, yaze::zelda3::atlas::AtlasBadges::big_chest, yaze::zelda3::atlas::AtlasBadges::bk_chest, yaze::zelda3::atlas::AtlasBadges::bk_drop, yaze::zelda3::atlas::DungeonAtlasRoom::blockset, yaze::zelda3::BuildRoomCensus(), yaze::zelda3::atlas::AtlasBadges::c, yaze::zelda3::atlas::DungeonAtlasInput::census, yaze::zelda3::atlas::DungeonAnnotation::code, yaze::zelda3::atlas::AtlasArea::code, yaze::zelda3::CollectRoomLinks(), yaze::zelda3::atlas::DungeonAnnotation::color, yaze::zelda3::atlas::AtlasArea::color, yaze::zelda3::atlas::AtlasPlan::color, yaze::zelda3::atlas::DungeonAnnotation::color_origin, yaze::zelda3::atlas::AtlasArea::color_origin, yaze::zelda3::atlas::DungeonAtlas::counts, yaze::zelda3::atlas::Origin::Default(), yaze::zelda3::atlas::DungeonAtlasRoom::doors, yaze::zelda3::atlas::AtlasAnnotations::dungeons, yaze::zelda3::atlas::DungeonAtlas::edges, yaze::zelda3::atlas::DungeonAtlasRoom::empty, yaze::zelda3::RoomCensusEntry::empty, yaze::zelda3::atlas::AtlasLink::entrance, yaze::zelda3::RoomCensusInput::entrances, yaze::zelda3::atlas::DungeonAtlas::expanded_entrance_tables, yaze::zelda3::RoomCensus::expanded_entrance_tables, yaze::zelda3::atlas::DungeonAtlasInput::extras, yaze::zelda3::atlas::AtlasAnnotations::files, yaze::zelda3::atlas::AtlasSymbolRead::found, yaze::zelda3::atlas::DungeonAtlasCounts::free, yaze::zelda3::atlas::AtlasLink::from, yaze::zelda3::atlas::AtlasPlan::has_color, yaze::zelda3::RoomLinkFacts::hole_sprite, yaze::zelda3::atlas::DungeonAtlasCounts::in_use, yaze::zelda3::atlas::AtlasLink::index, yaze::zelda3::atlas::DungeonAtlasRoom::interior, yaze::zelda3::atlas::DungeonAtlasCounts::interior, yaze::zelda3::RoomCensusEntry::interior, yaze::zelda3::IsDungeonRoomId(), chest::item, yaze::zelda3::atlas::AtlasAnnotations::items, yaze::zelda3::atlas::AtlasBadges::k_chest, yaze::zelda3::atlas::AtlasBadges::k_drop, yaze::zelda3::atlas::AtlasBadges::k_pot, kAnnotation, kAtlasInteriorColor, kAtlasNoOwnerColor, kAtlasOtherColor, kDefault, kDungeon, kEntrance, yaze::zelda3::kEntrance, yaze::zelda3::atlas::AtlasPlan::key, yaze::zelda3::atlas::DungeonAtlas::key_table, kFree, yaze::zelda3::kFree, kHole, yaze::zelda3::kHole, yaze::zelda3::kHolewarp, yaze::zelda3::atlas::Origin::kind, yaze::zelda3::atlas::AtlasLink::kind, yaze::zelda3::atlas::AtlasArea::kind, kInUse, yaze::zelda3::kInUse, yaze::zelda3::kNone, kOrphan, kPit, kPitDamage, yaze::zelda3::kPits, kReclaimable, yaze::zelda3::kReclaimable, kReserved, kSpawn, yaze::zelda3::kSpawn, yaze::zelda3::kSprite, kStair, yaze::zelda3::kStair, kSymbol, yaze::zelda3::kTag, kTagPit, kWarpTag, yaze::zelda3::kWarpTag, kWarpTiles, yaze::zelda3::kWarpTiles, yaze::zelda3::atlas::AtlasLink::label, yaze::zelda3::atlas::AtlasPlan::label, yaze::zelda3::atlas::DungeonAtlas::legend_notes, yaze::zelda3::atlas::AtlasAnnotations::legend_notes_dungeon, yaze::zelda3::atlas::AtlasAnnotations::links, yaze::zelda3::atlas::DungeonAtlasRoom::links_in, yaze::zelda3::atlas::DungeonAtlasRoom::links_out, yaze::zelda3::atlas::AtlasBadges::m, yaze::zelda3::atlas::DungeonAnnotation::name, yaze::zelda3::atlas::DungeonAtlasRoom::name, yaze::zelda3::atlas::AtlasArea::name, yaze::zelda3::atlas::AtlasPlan::name, yaze::zelda3::atlas::DungeonAtlasRoom::name_origin, yaze::zelda3::atlas::AtlasLink::note, yaze::zelda3::atlas::DungeonAtlasRoom::note, yaze::zelda3::atlas::AtlasPlan::note, yaze::zelda3::RoomCensusEntry::object_count, yaze::zelda3::atlas::DungeonAtlasRoom::objects, yaze::zelda3::atlas::DungeonAnnotation::origin, yaze::zelda3::atlas::AtlasLink::origin, yaze::zelda3::atlas::AtlasArea::origin, yaze::zelda3::atlas::AtlasPlan::origin, yaze::zelda3::atlas::DungeonAtlasCounts::orphan, yaze::zelda3::RoomCensusEntry::orphan, yaze::zelda3::atlas::AtlasBadges::other, OuterWallDoors(), yaze::zelda3::atlas::AtlasLink::ow_map, yaze::zelda3::atlas::DungeonAtlasRoom::owner, yaze::zelda3::atlas::AtlasArea::owner, yaze::zelda3::RoomCensusEntry::owner_index, yaze::zelda3::atlas::DungeonAtlasRoom::owner_name, yaze::zelda3::RoomCensus::owners, yaze::zelda3::atlas::DungeonAtlas::owners_from_project, yaze::zelda3::RoomCensus::owners_from_project, PairDoorEdges(), yaze::zelda3::atlas::DungeonAtlasRoom::pit_damage, yaze::zelda3::atlas::AtlasAnnotations::plans, yaze::zelda3::atlas::DungeonAtlas::plans, yaze::zelda3::atlas::DungeonAtlasRoom::reached, yaze::zelda3::RoomCensusEntry::reached, yaze::zelda3::atlas::DungeonAtlasRoom::reasons, yaze::zelda3::RoomCensusEntry::reasons, yaze::zelda3::atlas::DungeonAtlasCounts::reclaimable, yaze::zelda3::atlas::Origin::Registry(), yaze::zelda3::atlas::DungeonAtlasInput::registry_room_names, yaze::zelda3::atlas::DungeonAtlasCounts::reserved, yaze::zelda3::atlas::Origin::Rom(), yaze::zelda3::atlas::DungeonAtlas::rom, yaze::zelda3::atlas::DungeonAtlasInput::rom, yaze::zelda3::atlas::DungeonAtlasRoom::room_id, yaze::zelda3::atlas::AtlasAnnotations::rooms, yaze::zelda3::atlas::AtlasPlan::rooms, yaze::zelda3::atlas::DungeonAtlas::rooms, yaze::zelda3::RoomCensusInput::rooms, yaze::zelda3::RoomCensus::rooms, yaze::zelda3::RoomCensusEntry::sprite_count, yaze::zelda3::atlas::DungeonAtlasRoom::sprites, yaze::zelda3::RoomLinkFacts::stair_slot_estimated, yaze::zelda3::atlas::DungeonAtlasRoom::status, yaze::zelda3::atlas::AtlasPlan::status, yaze::zelda3::RoomCensusEntry::status, yaze::zelda3::atlas::DungeonAtlasRoom::status_origin, yaze::zelda3::atlas::AtlasLink::style, yaze::zelda3::atlas::Origin::Symbol(), yaze::zelda3::atlas::AtlasAnnotations::symbol_links, yaze::zelda3::atlas::DungeonAtlasInput::symbol_reads, yaze::zelda3::atlas::DungeonAtlas::symbols, yaze::zelda3::atlas::DungeonAtlasInput::symbols_path, yaze::zelda3::atlas::DungeonAtlasRoom::tag1, yaze::zelda3::atlas::DungeonAtlasRoom::tag2, yaze::zelda3::atlas::AtlasAnnotations::title, yaze::zelda3::atlas::DungeonAtlas::title, yaze::zelda3::atlas::AtlasAnnotations::title_origin, yaze::zelda3::atlas::DungeonAtlas::title_origin, yaze::zelda3::atlas::AtlasLink::to, yaze::zelda3::atlas::AtlasSymbolRead::values, yaze::zelda3::RoomCensus::vanilla_owner_names, yaze::zelda3::atlas::DungeonAtlasRoom::vanilla_similarity, yaze::zelda3::RoomCensusEntry::vanilla_similarity, yaze::zelda3::atlas::DungeonAtlas::warnings, and yaze::zelda3::RoomCensusInput::warp_tag_ids.

Referenced by yaze::cli::handlers::AtlasRenderCommandHandler::ExecuteWithContext().

◆ DoorCategoryName()

const char * yaze::zelda3::atlas::DoorCategoryName ( DoorCategory category)

Definition at line 67 of file dungeon_door_edges.cc.

References yaze::zelda3::category, kBigKey, kBomb, kExit, kIgnore, kKey, kKeyStairs, kOneSided, kOpen, kOther, and kShutter.

Referenced by DungeonAtlasToJson().

◆ DoorCategoryForType()

DoorCategory yaze::zelda3::atlas::DoorCategoryForType ( int door_type)

Definition at line 93 of file dungeon_door_edges.cc.

References kBigKey, kBomb, kExit, kIgnore, kKey, kKeyStairs, kOneSided, kOpen, kOther, and kShutter.

Referenced by OuterWallDoors().

◆ OuterWallDoors()

std::vector< AtlasDoor > yaze::zelda3::atlas::OuterWallDoors ( const std::vector< AtlasDoorFact > & doors)

Definition at line 131 of file dungeon_door_edges.cc.

References yaze::zelda3::atlas::AtlasDoor::category, yaze::zelda3::category, DoorCategoryForType(), kExit, kIgnore, yaze::zelda3::atlas::AtlasDoor::pos, yaze::zelda3::atlas::AtlasDoor::type, yaze::zelda3::atlas::AtlasDoor::type_name, and yaze::zelda3::atlas::AtlasDoor::wall.

Referenced by BuildDungeonAtlas().

Here is the call graph for this function:

◆ PairDoorEdges()

std::vector< DoorEdge > yaze::zelda3::atlas::PairDoorEdges ( const std::vector< std::vector< AtlasDoor > > & doors_by_room)

Definition at line 171 of file dungeon_door_edges.cc.

References yaze::zelda3::atlas::DoorEdge::a, yaze::zelda3::atlas::DoorEdge::b, yaze::zelda3::atlas::DoorEdge::both_sides, yaze::zelda3::atlas::AtlasDoor::category, yaze::zelda3::atlas::DoorEdge::category, yaze::zelda3::category, yaze::zelda3::atlas::DoorEdge::dir, kOneSided, kOpen, yaze::zelda3::atlas::DoorEdge::one_sided_type, yaze::zelda3::atlas::AtlasDoor::pos, yaze::zelda3::atlas::DoorEdge::pos, yaze::zelda3::atlas::AtlasDoor::type_name, yaze::zelda3::atlas::DoorEdge::types, and yaze::zelda3::atlas::AtlasDoor::wall.

Referenced by BuildDungeonAtlas().

Variable Documentation

◆ kAtlasRoomCount

constexpr int yaze::zelda3::atlas::kAtlasRoomCount = 0x128
inlineconstexpr

Definition at line 35 of file atlas_annotations.h.

Referenced by yaze::zelda3::atlas::anonymous_namespace{atlas_annotations.cc}::ReadArea(), yaze::zelda3::atlas::anonymous_namespace{atlas_annotations.cc}::ReadAtlasV1(), yaze::zelda3::atlas::anonymous_namespace{atlas_annotations.cc}::ReadOracleRoomV0(), yaze::zelda3::atlas::anonymous_namespace{atlas_annotations.cc}::ReadPlan(), and yaze::zelda3::atlas::anonymous_namespace{atlas_annotations.cc}::ReadSymbolLink().

◆ kAtlasMapCount

constexpr int yaze::zelda3::atlas::kAtlasMapCount = 0xA0
inlineconstexpr

Definition at line 36 of file atlas_annotations.h.

Referenced by yaze::zelda3::atlas::anonymous_namespace{atlas_annotations.cc}::ReadAtlasV1(), yaze::zelda3::atlas::anonymous_namespace{atlas_annotations.cc}::ReadGateKey(), yaze::zelda3::atlas::anonymous_namespace{atlas_annotations.cc}::ReadOracleOverworldV0(), yaze::zelda3::atlas::anonymous_namespace{atlas_annotations.cc}::ReadOverworldV1(), and yaze::zelda3::atlas::anonymous_namespace{atlas_annotations.cc}::ReadSection().

◆ kAtlasOtherColor

constexpr AtlasColor yaze::zelda3::atlas::kAtlasOtherColor {120, 120, 132}
inlineconstexpr

Definition at line 27 of file atlas_defaults.h.

Referenced by BuildDungeonAtlas().

◆ kAtlasNoOwnerColor

constexpr AtlasColor yaze::zelda3::atlas::kAtlasNoOwnerColor {30, 33, 40}
inlineconstexpr

Definition at line 28 of file atlas_defaults.h.

Referenced by BuildDungeonAtlas().

◆ kAtlasInteriorColor

constexpr AtlasColor yaze::zelda3::atlas::kAtlasInteriorColor {86, 90, 102}
inlineconstexpr

Definition at line 29 of file atlas_defaults.h.

Referenced by BuildDungeonAtlas(), and VanillaDungeonDefaults().

◆ kDungeonAtlasJsonSchema

constexpr char yaze::zelda3::atlas::kDungeonAtlasJsonSchema[] = "yaze.atlas.dungeon/1"
inlineconstexpr

Definition at line 15 of file atlas_json.h.

Referenced by DungeonAtlasToJson(), and yaze::cli::handlers::AtlasRenderCommandHandler::ExecuteWithContext().
